Price per set as shown

Connector System 4mm

Rated Voltage 1000V DC (IEC)

Rated Current 30A

Test Voltage 6kV(50HZ, 1min)

Ambient Temperature Range -40°C - +90°C (IEC) / -40° - +75°C (UL)

Upper Limiting Temperature Range +105°C (IEC)

Degree of protection when Connected IP67  / Unconnected IP2X

Contact Resistance of Plug Connectors 0.5m

Safety class II

Contact Material Copper Alloy, Tin Plated

Insulation Material PC/PA

Locking System Snap-in

Flame Class UL-94-V0

Salt Mist Spray Test, degree of severity 5 -  IEC 6068-2-52
